Rear glass release circuit for Chevrolet Astro I (1985-2005)
Rear glass release circuit
BLK WIRE
CIG LTR FUSE 13
DOOR LOCK RELAY (RIGHT KICK PANEL)
DOOR LOCKS SYSTEM
FROM RADIO CON- NECTORS BREAKOUT)
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF DASH,
IN RIGHT KICK PANEL)
LIFTGLASS LOCK/UNLOCK RELAY (RIGHT REAR QUARTER PANEL) LOCK
LIFTGLASS LOCK/UNLOCK RELEASE SWITCH RELEASE SWITCH
LIFTGLASS RELEASE ACTUATOR
LOCK UNLOCK
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PPL
PWR-ACCY CIRCUIT BREAKER
TAN WIRE
UNLOCK
