Base radio circuit for Chevrolet Astro I (1985-2005)

Base radio circuit

Astro Chevrolet I (1985-2005): Base radio circuit

Get access

1 2 3 4 5 6 7 8 9 10 LF (-) LF (+) RF (-) RF (+) GRD DISPLAY DIM SIG PANEL LIGHT ANTENNA COAXIAL CABLE BLK WIRE BRN WIRE DK BLU WIRE DK GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH) RDO ACCY FUSE 2 IGNITION VOLTAGE B+ LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PPL/WHT WIRE RADIO RADIO BATT FUSE 19 RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SPEAKER RR (-) RR (+) LR (-) LR (+) TAN WIRE YEL WIRE
