Exterior lamps circuit for Chevrolet Astro I (1985-2005)

BACK-UP LAMPS CIRCUIT BLK WIRE BLU WIRE BODY CONTROL MODULE (ABOVE RADIO) BREAKOUT) BRN WIRE CENTER HIGH MOUNTED STOP LAMP (CHMSL) CHMSL RESISTOR (ON LEFT KICK PANEL) CONVENIENCE CENTER (NEAR LEFT KICK PANEL) CRUISE CONTROL SYSTEM DK BLU WIRE DK GRN WIRE GRN WIRE HAZ SW TN SW HAZARD HEAD AUTO HEADLAMP, PANEL DIMMER SWITCH HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK PARK LPS FUSE 9 INSTRU- MENT PANEL CLUSTER INTERIOR LIGHT SYSTEM LEFT FRONT MARKER LAMP LEFT TAIL/ STOP/ TURN SIGNAL LAMP LEFT REAR MARKER LAMP LEFT TURN IND LICENSE LAMP LT BLU WIRE LT GRN WIRE LT TURN SIG IN RT TURN SIG IN MULTI- FUNCTION TURN SIGNAL LEVER NCA WIRE NORMAL OFF LEFT TURN SWITCH OFF RIGHT TURN SWITCH ORG/ WIRE PARK PARK LAMP RELAY (IN CONVEN- IENCE CENTER) PL RLY ENABLE PL INPUT PNK WIRE PPL RED WIRE RIGHT FRONT MARKER LAMP RIGHT FRONT PARK/ TURN SIGNAL LAMP RIGHT TAIL/ STOP/ TURN SIGNAL LAMP RIGHT REAR MARKER LAMP RIGHT TURN IND SOUND SYSTEMS STOP LAMP SWITCH (ABOVE BRAKE PEDAL) STOP/ HAZ FUSE 1 TAN WIRE TURN B/U FUSE 16 TURN SIGNAL/ HAZARD FLASHER MODULE (IN CONVENIENCE CENTER) UNDERHOOD FUSE/RELAY CENTER (ON LEFT SIDE OF FIREWALL) UPFIT- BAT MAXI FUSE WHT WIRE YEL WIRE
