Defoggers circuit for Chevrolet Astro I (1985-2005)
Defoggers circuit
BLK WIRE
BRN WIRE
DEFOGGER ON INDICATOR
HOT AT ALL TIMES HTD MIR/ RR-DEFOG FUSE
HOT IN RUN
HTR A/C FUSE 12
HVAC CONTROL ASSEMBLY
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
PPL
REAR DEFOGGER SWITCH
REAR DEFOGGER TIMER RELAY
REAR WINDOW DEFOGGER GRID
RED WIRE
RR DEFOG FUSE 5
TIMER
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF FIREWALL)
