Chevrolet Astro I (1985-2005) w/ power mirrors Wiring diagram
This page shows the only wiring diagram for the component.w/ power mirrors, which is found in the car Chevrolet Astro I (1985-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ power mirrors (1 of 1)
2 3 4 5 6 7 PPL
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CONVENIENCE CENTER (LEFT OF I/P FUSE BLOCK, BY LEFT KICK PANEL)
COVER SWITCH
DK BLU WIRE
DK BLU/WHT WIRE
DOME LAMP SWITCH
DOME LMP DEFEAT SWITCH
DRIVER DOOR LOCK SWITCH
DRIVER WINDOW MASTER SWITCH
FRONT PASSENGER DOOR LOCK SWITCH
FRONT PASSENGER WINDOW SWITCH
HEADLAMP, PANEL DIMMER SWITCH
I/P COMPARTMENT LAMP
LEFT VANITY MIRROR LAMP
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PARK LAMP SWITCH
PPL
REAR DOOR JAMB SWITCH
RIGHT VANITY MIRROR LAMP
W/ POWER MIRRORS
W/ REAR RADIO CONTROL ONLY
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> W/ POWER MIRRORS
