Chevrolet Astro I (1985-2005) vss lf whl spd sens sig rf whl spd sens ret Wiring diagram
This page shows the only wiring diagram for the component.vss lf whl spd sens sig rf whl spd sens ret, which is found in the car Chevrolet Astro I (1985-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vss lf whl spd sens sig rf whl spd sens ret (1 of 1)
650 442 GROUND FUSE OUTPUT
ABS FUSE
ABS IND.
BLK WIRE
BRAKE FUSE 18
BRAKE IND
BRAKE PRESSURE DIFFERENTIAL SWITCH (ON BRAKE PRESSURE MODULATOR VALVE ASSEMBLY)
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DK GRN WIRE
FUSE OUTPUT LF WHL SPD SENS RET RF WHL SPD SENS SIG
GRY WIRE
HOT AT ALL TIMES
HOT IN
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
INSTRUMENT PANEL CLUSTER
LEFT FRONT WHEEL SPEED SENSOR
LT BLU WIRE
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL BRAKE FLUID LVL SW
PPL BRAKE SW OUTPUT SERIAL DATA
RADIO BATT FUSE 19
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RUN WIRE
SPLICE PACK
STOP LAMP SWITCH (ABOVE BRAKE PEDAL)
TAN WIRE
TCC BRAKE SW/ CRUISE CTRL RELEASE SIG PPL
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF FIREWALL)
VEHICLE SPEED OUT
VSS LF WHL SPD SENS SIG RF WHL SPD SENS RET
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit -> VSS LF WHL SPD SENS SIG RF WHL SPD SENS RET
