Chevrolet Astro I (1985-2005) lt turn sig in rt turn sig in wiring diagram
This page shows the only wiring diagram for the component.lt turn sig in rt turn sig in, which is found in the car Chevrolet Astro I (1985-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
lt turn sig in rt turn sig in wiring diagram (1 of 1)
BACK-UP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (ABOVE RADIO)
BREAKOUT)
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
CHMSL RESISTOR (ON LEFT KICK PANEL)
CONVENIENCE CENTER (NEAR LEFT KICK PANEL)
CRUISE CONTROL SYSTEM
DK BLU WIRE
DK GRN WIRE
GRN WIRE
HAZ SW TN SW
HAZARD
HEAD AUTO
HEADLAMP, PANEL DIMMER SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK PARK LPS FUSE 9
INSTRU- MENT PANEL CLUSTER
INTERIOR LIGHT SYSTEM
LEFT FRONT MARKER LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP LEFT REAR MARKER LAMP
LEFT TURN IND
LICENSE LAMP
LT BLU WIRE
LT GRN WIRE
LT TURN SIG IN RT TURN SIG IN
MULTI- FUNCTION TURN SIGNAL LEVER
NCA WIRE
NORMAL
OFF LEFT TURN SWITCH
OFF RIGHT TURN SWITCH
ORG/ WIRE
PARK
PARK LAMP RELAY (IN CONVEN- IENCE CENTER)
PL RLY ENABLE PL INPUT
PNK WIRE
PPL
RED WIRE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP RIGHT REAR MARKER LAMP
RIGHT TURN IND
SOUND SYSTEMS
STOP LAMP SWITCH (ABOVE BRAKE PEDAL)
STOP/ HAZ FUSE 1
TAN WIRE
TURN B/U FUSE 16
TURN SIGNAL/ HAZARD FLASHER MODULE (IN CONVENIENCE CENTER)
UNDERHOOD FUSE/RELAY CENTER (ON LEFT SIDE OF FIREWALL) UPFIT- BAT MAXI FUSE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LT TURN SIG IN RT TURN SIG IN
