Chevrolet Astro I (1985-2005) left front switch Wiring diagram
This page shows the only wiring diagram for the component.left front switch, which is found in the car Chevrolet Astro I (1985-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front switch (1 of 1)
AUTO DOWN MODULE
BLK WIRE
BRN WIRE
DK BLU WIRE
DRIVER WINDOW MASTER SWITCH
DRIVER WINDOW MOTOR
FRONT PASSENGER WINDOW MOTOR
FRONT PASSENGER WINDOW SWITCH
HOT IN RAP
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
ILLUM
LEFT FRONT SWITCH
LT BLU WIRE
RIGHT FRONT SWITCH
SOLID STATE
TAN WIRE
UP DN
WINDOWS CIRCUIT BREAKER
YEL WIRE
Go to component -> Power windows circuit -> LEFT FRONT SWITCH
