Chevrolet Astro I (1985-2005) key-in ignition sw Wiring diagram
This page shows the only wiring diagram for the component.key-in ignition sw, which is found in the car Chevrolet Astro I (1985-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key-in ignition sw (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLOCK
BLU WIRE
BODY CONTROL MODULE (BCM) (ABOVE RADIO)
BRAKE PRESSURE DIFFERENTIAL SWITCH (ON BRAKE PRESSURE MODULATOR VALVE ASSY)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DR DOOR AJAR SW
DRIVER DOOR JAMB SWITCH
EXTERIOR LIGHTS
GRY WIRE
HEAD
HEADLAMP, PANEL DIMMER SWITCH
HOT AT ALL TIMES
I/P FUSE
IGNITION KEY ALARM SWITCH (CLOSED W/KEY IN IGNITION)
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
KEY-IN IGNITION SW
LEFT SEAT BELT SW
LEFT TURN SIGNAL
LT BLU WIRE
LT GRN WIRE
MULTI- FUNCTION
NCA WIRE
OFF
ORG/ WIRE
PARK
PARK BRAKE
PARK BRAKE SW SIG
PARK LAMP VOLT
PK LPS FUSE 9
RIGHT TURN SIGNAL
SEAT BELT BUCKLE SWITCH (ON DRIVER'S SEAT BELT BUCKLE)
SERIAL DATA
SERIAL DATA SWITCH SIGNAL PPL
SWITCH (BASE OF PARK BRAKE LEVER)
TAN/WHT WIRE
TURN SIGNAL LEVER
VEHICLE SPEED SIG
VSS SIGNAL
WHT WIRE
Go to component -> Warning systems circuit -> KEY-IN IGNITION SW
