Chevrolet Astro I (1985-2005) high control low control low control Wiring diagram
This page shows the only wiring diagram for the component.high control low control low control, which is found in the car Chevrolet Astro I (1985-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high control low control low control (1 of 1)
AIR BAG FUSE
AIR BAG IND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CLASS 2 SERIAL DATA
CLASS 2 SERIAL DATA LOGIC
DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH) PPL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
GAGES FUSE
GRN WIRE
GROUND
GRY WIRE
HIGH CONTROL DATA
HIGH CONTROL LOW CONTROL LOW CONTROL
HOT IN RUN, START
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
IGN
IGNITION
INFLATABLE RESTRAINT I/P MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT)
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
NCA WIRE
PNK WIRE
PPL
SENSOR SIGNAL SENSOR GND
SHORTING BAR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit -> HIGH CONTROL LOW CONTROL LOW CONTROL
