Chevrolet Astro I (1985-2005) front passenger window switch Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger window switch, in which he is found in the car Chevrolet Astro I (1985-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger window switch (1 of 2)
2 3 4 5 6 7 PPL
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CONVENIENCE CENTER (LEFT OF I/P FUSE BLOCK, BY LEFT KICK PANEL)
COVER SWITCH
DK BLU WIRE
DK BLU/WHT WIRE
DOME LAMP SWITCH
DOME LMP DEFEAT SWITCH
DRIVER DOOR LOCK SWITCH
DRIVER WINDOW MASTER SWITCH
FRONT PASSENGER DOOR LOCK SWITCH
FRONT PASSENGER WINDOW SWITCH
HEADLAMP, PANEL DIMMER SWITCH
I/P COMPARTMENT LAMP
LEFT VANITY MIRROR LAMP
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PARK LAMP SWITCH
PPL
REAR DOOR JAMB SWITCH
RIGHT VANITY MIRROR LAMP
W/ POWER MIRRORS
W/ REAR RADIO CONTROL ONLY
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> FRONT PASSENGER WINDOW SWITCH
Wiring diagram front passenger window switch (2 of 2)
AUTO DOWN MODULE
BLK WIRE
BRN WIRE
DK BLU WIRE
DRIVER WINDOW MASTER SWITCH
DRIVER WINDOW MOTOR
FRONT PASSENGER WINDOW MOTOR
FRONT PASSENGER WINDOW SWITCH
HOT IN RAP
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
ILLUM
LEFT FRONT SWITCH
LT BLU WIRE
RIGHT FRONT SWITCH
SOLID STATE
TAN WIRE
UP DN
WINDOWS CIRCUIT BREAKER
YEL WIRE
Go to component -> Power windows circuit -> FRONT PASSENGER WINDOW SWITCH
