Chevrolet Astro I (1985-2005) data clss 2 Wiring diagram
This page shows the only wiring diagram for the component.data clss 2, which is found in the car Chevrolet Astro I (1985-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data clss 2 (1 of 1)
59 58 DATA CLSS 2 DATA CLSS 2
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (ABOVE RADIO)
CONVENIENCE CENTER (LEFT OF I/P FUSE BLOCK)
DATA CLSS 2
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER
GRY WIRE
HOT AT ALL TIMES AUX POWER FUSE 7
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT)
INSTRUMENT PANEL CLUSTER
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (BELOW UNDERHOOD FUSE BLOCK, ON LEFT SIDE OF FIREWALL)
PPL
SPLICE PACK
TRANSFER CASE SHIFT CONTROL MODULE (BEHIND LEFT KICK PANEL)
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit -> DATA CLSS 2
