Cadillac XT6 I (2019-2024) sensor lamp ctrl wiring diagram
This page shows the only wiring diagram for the component.sensor lamp ctrl, which is found in the car Cadillac XT6 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sensor lamp ctrl wiring diagram (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DATA 2 (+)
DRIVER INFORMATION CENTER DISPLAY
DRIVER OUTSIDE REAR- VIEW MIRROR
GMLAN
GRN WIRE
GRN/VIO WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HANDS-FREE LIFTGATE SENSOR LAMP
INSTRUMENT CLUSTER
KEYLESS ENTRY CONTROL MODULE
LEFT CORNERING LAMP
LEFT FRONT FASCIA MULTI- FUNCTION LED
LEFT FRONT FASCIA MULTI-FUNCTION LAMP ASSEMBLY
LEFT FRONT SIDE MARKER LAMP
LEFT TURN IND
LEFT TURN SIGNAL REPEATER LAMP
LO SPD
LOGIC
LOW SPD GMLAN
PARKS LAMPS IND
RIGHT TURN IND
SENSOR LAMP CTRL
SER
SERIAL DATA
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRY WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (4 of 5) -> SENSOR LAMP CTRL
