Cadillac XT4 I (2018-2023) windshield defrost ind sync ind defrost, lower air outlet ind Wiring diagram
This page shows the only wiring diagram for the component.windshield defrost ind sync ind defrost, lower air outlet ind, which is found in the car Cadillac XT4 I (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield defrost ind sync ind defrost, lower air outlet ind (1 of 1)
A/C COMPRESSOR
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR SOLENOID VALVE
A/C IND
A/C SWITCH
AIR QUALITY SENSOR
AUTO IND UPPER AIR OUTLET IND
AUTO SWITCH
BLK WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/YEL WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR
DATA BUS 9
DEFROST, LOWER AIR OUTLET SWITCH
FAN DOWN SWITCH
FAN UP SWITCH
GRN/BLU WIRE
GRN/YEL WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HVAC CONTROLS
INSTRUMENT PANEL FUSE BLOCK
LEFT TEMPERATURE DOWN SWITCH
LEFT TEMPERATURE UP SWITCH
LOGIC
LOWER AIR OUTLET IND
LOWER AIR OUTLET SWITCH
ON/OFF IND
ON/OFF SWITCH
POWER SUPPLY TRANSFORMER
RECIRCULATION IND
RECIRCULATION SWITCH
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT TEMPERATURE DOWN SWITCH
RIGHT TEMPERATURE UP SWITCH
SERIAL
SPLY VOLT 1
SYNC SWITCH
UNDERHOOD FUSE BLOCK
UPPER AIR OUTLET SWITCH
VIO/GRY WIRE
VIO/WHT WIRE
W/ AIR IONIZER
WHT WIRE
WINDSHIELD DEFROST IND SYNC IND DEFROST, LOWER AIR OUTLET IND
WINDSHIELD DEFROST SWITCH
Go to component -> Automatic a/c circuit (2 of 4) -> WINDSHIELD DEFROST IND SYNC IND DEFROST, LOWER AIR OUTLET IND
