Cadillac XT4 I (2018-2023) w/ ashtray cigarette lighter Wiring diagram
This page shows the only wiring diagram for the component.w/ ashtray cigarette lighter, which is found in the car Cadillac XT4 I (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ ashtray cigarette lighter (1 of 1)
AUTO STOP START INDICATOR CTRL
AUXILIARY AUDIO INPUT
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (LOWER CENTER OF DASH)
CIGARETTE LIGHTER RECEPTACLE
COMPUTER DATA LINES SYSTEM
DIMMER SW LOW REF
DIMMER SW SIG
DOME LP OFF INDICATOR CTRL
DRIVE MODE SELECT SWITCH
GRN WIRE
GRN/GRY WIRE
GRY WIRE
GRY/GRN WIRE
HEAD
HEAD-UP DISPLAY SWITCH
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HVAC CONTROLS
IGNITION MODE SWITCH
INDICATOR DIMMING CTRL
INSTRUMENT PANEL DIMMER SWITCH
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LED BACKLIGHT DIMMING CTRL
LEFT REAR WINDOW SWITCH
LOGIC
PARK AUTO OFF
PARK LP SIG
RED/YEL WIRE
RIGHT REAR WINDOW SWITCH
TURN SIGNAL/ MULTI-FUNCTION SWITCH
USB RECEPTACLE (W/ MANUAL LIFT GATE)
W/ ASHTRAY CIGARETTE LIGHTER
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> W/ ASHTRAY CIGARETTE LIGHTER
