Cadillac XT4 I (2018-2023) rr closure hndl sw open sig Wiring diagram
This page shows the only wiring diagram for the component.rr closure hndl sw open sig, which is found in the car Cadillac XT4 I (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr closure hndl sw open sig (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (LOWER CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GMLAN SERIAL DATA
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LGATE AJAR SW SIG 1
LICENSE PLATE LAMP
LIFTGATE DOOR LOCK ACTUATOR
LIFTGATE UNLATCH RELAY
LIFTGATE UNLATCH SWITCH
LIFTGLASS/RR COMPT LID MTR REL CTRL
LOGIC
LOW SPD GMLAN SERIAL DATA
RED WIRE
RED/WHT WIRE
RR CLOSURE HNDL SW OPEN SIG
UNDERHOOD FUSE BLOCK
VIO/GRY WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Liftgate release circuit -> RR CLOSURE HNDL SW OPEN SIG
