Cadillac XT4 I (2018-2023) obj sens sig Wiring diagram

3/4 5 VOLT REF AJAR SW SIG 1 AJAR SW SIG 2 AJAR SW SIG 3 BATT POS VOLT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY FACE SW SIG GMLAN SERIAL DATA GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE HANDS-FREE CLOSURE RELEASE SENS SIG 1 HANDS-FREE CLOSURE RELEASE SENS LO REFR 1 HANDS-FREE CLOSURE RELEASE SENS SIG 2 HANDS-FREE CLOSURE RELEASE SENS LO REFR 2 HANDS-FREE LIFTGATE SENSOR CONTROL MODULE HOT AT ALL TIMES INSTRUMENT CLUSTER INTERIOR LIFTGATE CONTROL SWITCH LATCH MTR CLOSE CTRL LATCH MTR OPEN CTRL LEFT LIFTGATE OBJECT SENSOR LIFTGATE CLOSE SWITCH LIFTGATE CONTROL MODULE LIFTGATE LATCH ASSEMBLY LIFTGATE MOTOR ASSEMBLY (UNDER LEFT SIDE OF LIFTGATE) LIFTGATE UNLATCH SWITCH LOGIC LOW REF LOW SPEED GMLAN SERIAL DATA 2 LOWER HANDS-FREE LIFTGATE SENSOR MAX MTR CLOSE CTRL MTR OPEN CTRL MTR RELEASE CTRL 2 NCA WIRE NETWORK BUS 18 OBJ SENS SIG OFF ON/OFF SW SIG OPEN/CLOSE SW SIG POS SIG 1 POS SIG 2 REAR OPEN/ CLOSE SWITCH RED/BRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT LIFTGATE OBJECT SENSOR RR CLOSURE OPEN SW LED CTRL SW OPEN SIG UNDERHOOD FUSE BLOCK UPPER HANDS-FREE LIFTGATE SENSOR W/ HANDSFREE W/O HANDSFREE WHT WIRE WHT/BLK WIRE WHT/GRY WIRE YEL WIRE YEL/BLU WIRE
