Cadillac XT4 I (2018-2023) noise reduction microphone 3 low ref Wiring diagrams
This page contains all the electrical diagrams for the component. noise reduction microphone 3 low ref, in which he is found in the car Cadillac XT4 I (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram noise reduction microphone 3 low ref (1 of 2)
AUDIO AMPLIFIER
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CENTER INSTRUMENT PANEL SPEAKER
COMPUTER DATA LINES SYSTEM
ETHERNET BUS 6 (-)
FRONT CENTER SPKR (-) LOW REF
FRONT CENTER SPKR CONTROL (+)
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GROUND
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT DOOR SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT INSTRUMENT PANEL SPEAKER
LF SPKR 1 (-)
LF SPKR SIGNAL (-) 1
LF TWEETER SPKR CTRL (+)
LF TWEETER SPKR CTRL (-) LO REF
LO SPD GMLAN SER DATA 2
LR MIDRANGE SPKR (+) CTRL
LR MIDRANGE SPKR - LO REF
LR SPKR (-) CTRL
LR SPKR SIGNAL (-)
NOISE REDUCTION MICROPHONE 1 LOW REF
NOISE REDUCTION MICROPHONE 1 SIGNAL
NOISE REDUCTION MICROPHONE 2 LOW REF
NOISE REDUCTION MICROPHONE 2 SIGNAL
NOISE REDUCTION MICROPHONE 3 LOW REF
NOISE REDUCTION MICROPHONE 3 SIGNAL
NOISE REDUCTION MICROPHONE 4 RETURN
NOISE REDUCTION MICROPHONE 4 SIGNAL
RED/BRN WIRE
REPLICATED SIGNAL
RF SPEAKER SIG (-) 1
RF SPKR CONTROL (+) (1)
RF TWEETER SPKR (-) LO REF
RF TWEETER SPKR CTRL (+)
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER SPEAKER
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REAR COMPARTMENT SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR TWEETER SPEAKER
RR SPKR (-) CTRL
RR SPKR SIGNAL (-)
VIO/BLU WIRE
VIO/BRN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/WHT WIRE
Go to component -> Navigation circuit, w/ surround amplifier (5 of 5) -> NOISE REDUCTION MICROPHONE 3 LOW REF
