Cadillac XT4 I (2018-2023) hdlp auto high beam dim ctrl Wiring diagram
This page shows the only wiring diagram for the component.hdlp auto high beam dim ctrl, which is found in the car Cadillac XT4 I (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hdlp auto high beam dim ctrl (1 of 1)
AMBIENT LIGHT SENSOR SIG
AMBIENT LIGHT/ SUNLOAD SENSOR
AUTO
BATTERY POSITIVE VOLTAGE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (LOWER CENTER OF DASH)
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FTP
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HDLP AUTO HIGH BEAM DIM CTRL
HDLP DIMMER SW HIGH BEAM SIG
HDLP LOW BEAM RELAY CTRL
HDLP SW FLASH TO PASS SIG
HDLP SW HDLPS OFF SIG CTRL
HDLP SW ON SIG
HEAD
HIGH BEAM
HIGH SPD GMLAN SERIAL DATA (+) 1
HOT AT ALL TIMES
HVAC CONTROL MODULE
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT DRL CONTROL
LEFT HDLP LOW BEAM CTRL
LEFT HDLP LOW BEAM CTRL LEFT HDLP LOW BEAM CTRL
LO REF
LOW SPD GMLAN SERIAL DATA
OFF
PARK
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT FRONT DRL CONTROL
RIGHT HDLP HIG BEAM CTRL
SIG GND
SWITCH
TURN SIGNAL/MULTI-FUNCTION SWITCH
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit (1 of 3) -> HDLP AUTO HIGH BEAM DIM CTRL
