Cadillac XT4 I (2018-2023) anti-theft system Wiring diagrams

This page contains all the electrical diagrams for the component. anti-theft system, in which he is found in the car Cadillac XT4 I (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram anti-theft system (1 of 2)

ACC IGN VOLT ACC WAKEUP SERIAL DATA ACCELERATE SW SIG AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM BACKUP LP CTRL BATTERY POSITIVE VOLTAGE BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/VIO WIRE BODY CONTROL MODULE (LOWER CENTER OF DASH) BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/YEL WIRE CHARGE INDICATOR CTRL COMMUNICATION ENABLE COMPUTER DATA LINES SYSTEM COURTESY LP SW SIG CRUISE CONTROL SYSTEM DOOR LK ACTUATOR CTRL 2 DOOR LK ACTUATOR LK CTRL DOOR LK ACTUATOR UNLK CTRL DOOR LOCKS, ANTI-THEFT SYSTEMS DRIVER DOOR LOCK SW LOCK SIG DRIVER DOOR LOCK SW UNLOCK SIG ENGINE START/STOP SWITCH EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM FUEL DOOR LOCK RELAY CTRL GAP UP/DOWN SW SIG SET/COAST/RESUME/ GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HAZ SW LH TURN SIG HAZ SW RH TURN SIG HDLP DIMMER SW HI BEAM SIG HDLP SW FLASH TO PASS SIG HEADLIGHTS SYSTEM HI SPD GMLAN SERIAL DATA (-) (1) HOOD STATUS B SIG PUSH BUTTON START CHALLENGE ACTIVE SIG HORN SW SIG HORNS SYSTEM IGNITION MODE SWITCH IMMOBILIZER CTRL IMMOBILIZER LOW REF INADVERTENT PWR CTRL IND INTERIOR LP CTRL LED AMBIENT LIGHTING CTRL 1 LED BACKLIGHT DIMMING CTRL LEFT HDLP BULB OUTAGE REAR CLOSURE HANDLE SW OPEN SIG LF DRL CTRL LIFT GLASS/RR COMPT LID MTR REL CTRL LH HDLP LOW BEAM RLY CTRL LH PARK LP CTRL LIFT GATE AJAR SWITCH SIG (1) LIN SERIAL DATA BUS 1 LIN SERIAL DATA BUS 11 LIN SERIAL DATA BUS 15 LIN SERIAL DATA BUS 2 LIN SERIAL DATA BUS 3 MIRROR PUDDLE LAMP CTRL PASS DOOR LK SW UNLK CTRL PASSENGER DOOR LOCK SW LOCK CTRL POWER DISTRIBUTION SYSTEM REAR COMPT LID LP 2 CTRL REAR LICENSE LP CTRL REAR TURN LP FEEDBACK SIG REAR WIPER MTR RLY COIL CTRL RED WIRE RED/WHT WIRE RF TURN SIG LP CTRL RH HDLP LOW BEAM RLY CTRL RH PARK LP CTRL RIGHT HDLP BULB OUTAGE RR STOP LP CTRL RR TURN LP FEEDBACK SIG RR TURN SIG LP CTRL RUN/CRANK IGN 1 VOLT RUN/CRANK RLY COIL CTRL WINDSHIELD WIPER MTR RLY COIL CTRL SEATS SYSTEM SECURITY LOCK RELAY CONTROL SIGNAL GROUND STARTING/CHARGING SYSTEM STOP LP RLY COIL CTRL TAP UP/TAP DOWN SW SIG TRANSMISSIONS SYSTEM TRANSMISSIONS, CRUISE CONTROL SYSTEM VIO WIRE VIO/BLK WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE WHT/YEL WIRE WINDSHIELD WASHER SW SIG WINDSHIELD WIPER MTR PARK SW SIG BLOWER SPD FEEDBACK SIG WIPER SW HI SIG WIPER SW LOW REF WIPER SW LOW SIG WIPER/WASHER SYSTEM YEL WIRE YEL/BLU WIRE YEL/GRN WIRE

Go to component -> Body control modules circuit (2 of 2) -> ANTI-THEFT SYSTEM

Wiring diagram anti-theft system (2 of 2)

"CHECK ENGINE" IND CTRL A/C COMPRESSOR CLUTCH RLY CTRL A/C REFRIGERANT PRESS SENS SIG ACCELERATOR PEDAL POSITION LO REF 1 ACCELERATOR PEDAL POSITION LO REF 2 ACCELERATOR PEDAL POSITION SIG 1 ACCELERATOR PEDAL POSITION SIG 2 ACCESSORY WAKEUP SERIAL DATA AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES SYSTEM ANTI-THEFT SYSTEM BATT POS VOLT BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/WHT WIRE BRAKE POSITION SENS SIG BRN/RED WIRE BRN/WHT WIRE CAMSHAFT CAM W SIG CAMSHAFT CAM X GND CAMSHAFT CAM X SIG CAMSHAFT CAM Y GND CAMSHAFT CAM Z CTRL CAMSHAFT CAM Z GND CAMSHAFT CAM Z SIG CAMSHAFT EXHAUST LOBE AXIAL POSITION SIG (1) CAMSHAFT EXHAUST LOBE AXIAL POSITION SIG (2) CAMSHAFT INTAKE LOBE AXIAL POSITION SIG (1) CAMSHAFT INTAKE LOBE AXIAL POSITION SIG (2) CAMSHAFT STEPPER A CTRL CAMSHAFT STEPPER B CTRL CAMSHAFT STEPPER C CTRL CAMSHAFT STEPPER D CTRL CAMSHAFT STEPPER POSITION SEN 1 SIG CAMSHAFT STEPPER POSITION SEN 2 GND CAMSHAFT STEPPER POSITION SEN 2 SIG CAMSHAFT STEPPER POSITION SENS SIG COMPUTER DATA LINES SYSTEM COOLING FAN CTRL SIG COOLING FANS SYSTEM CRUISE/ETC/TCC BRAKE SIG ENGINE CONTROL MODULE (ENGINE COMPT, RIGHT SIDE OF BATTERY) FUEL PUMP PRIMARY RLY CTRL GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/YEL WIRE HEATER CORE OUTLET TEMP SIG HI SPD GMLAN SERIAL DATA (+) (3) HI SPD GMLAN SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA (-) 7 HOOD OPEN SW SIG MASS AIR FLOW SEN SIG OUTSIDE AMBIENT AIR TEMP SEN SIG POWERTRAIN MAIN RLY FUSED SUPLY 2 POWERTRAIN MAIN RLY FUSED SUPLY 3 POWERTRAIN RLY COIL CTRL RED/WHT WIRE RUN/CRANK IGNITION 1 VOLT SERIAL DATA BUS 24 SIG GND STARTER ENABLE RLY CTRL STARTER PINION SOL RLY CTRL STARTING/ CHARGING SYSTEM STEP CAM A CTRL STEP CAM B CTRL VIO/BLK WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/VIO WIRE YEL/WHT WIRE

Go to component -> Wiring diagram engine performance 2.0l vin 4 (10 of 10) -> ANTI-THEFT SYSTEM
