Cadillac XLR I (2003-2009) wiper dwell fuse 38 wiring diagram
This page shows the only wiring diagram for the component.wiper dwell fuse 38, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
wiper dwell fuse 38 wiring diagram (1 of 1)
ACCESSORY VOLT
ACCESSORY VOLTAGE SIGNAL
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
DIODE 1
DIODE 2
DK GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES WIPER FUSE 4
I/P FUSE BLOCK (FRONT OF RIGHT FRONT FOOTWELL, BEHIND CARPET)
LOGIC RUN/ CRANK RELAY CONTROL
LT BLU WIRE
LT GRN WIRE
OUTSIDE MOISTURE SENSOR WINDSHIELD WIPER SWITCH LOW SIGNAL
PARK SWITCH
PNK WIRE
PPL
RPA/H/C SEAT/WIPR RELAYS FUSE 14
RUN/ ACCESSORY POWER FUSE 35
RUN/ CRANK RELAY 7
SPLICE PACK
TO W/S WASH RELAY 36 (DIAGRAM 2 OF 2)
UNDER- HOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
WINDSHIELD HIGH WIPER MOTOR (UPPER REAR OF ENGINE COMPARTMENT)
WINDSHIELD WASHER SWITCH SIGNAL
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER SWITCH HIGH SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 2
WIPER
WIPER DWELL FUSE 38
WIPER HI/LO RELAY 41
WIPER ON/OFF RELAY 45
WIPER RUN/ACC RELAY 42
YEL WIRE
YEL YEL WIRE
Go to component -> Front wiper/washer & headlamp washer circuit (1 of 2) -> WIPER DWELL FUSE 38
