Cadillac XLR I (2003-2009) vertical posit sensor low reference horiz posit sensor ground Wiring diagram

BATTERY (B+) GROUND BATTERY B+ MEMORY 1 SW SIG MEMORY 2 SW SIG CLASS 2 SERIAL DATA BLK WIRE BODY CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) BRN WIRE BRN/WHT WIRE DK GRN WIRE DOWN SW SIG DR CONTROLS CIRCUIT BREAKER 34 DRIVER DOOR MODULE (DDM) (IN DRIVER'S DOOR) DRIVER DOOR SWITCH ASSEMBLY DRIVER MEMORY SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER OUTSIDE REARVIEW MIRROR (OUTSIDE OF DRIVER'S DOOR) EXIT SWITCH FRONT PASSENGER DOOR MODULE (FPDM) (IN FRONT DOOR) GROUND GRY WIRE GRY/BLK WIRE HORIZONTAL MOTOR HORIZONTAL POSITION SENSOR VERTICAL MOTOR HORIZONTAL POSITION SENSOR VERTICAL POSITION SENSOR HOT AT ALL TIMES I/P FUSE BLOCK (FRONT OF RIGHT FRONT FOOTWELL, BEHIND CARPET) L MIRR SIG LEFT SW SIG LO LT LOGIC LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE MEMORY 2 SWITCH MEMORY SEAT SWITCH MEMORY 1 SWITCH NCA WIRE ORG/WHT WIRE PASSENGER OUTSIDE REARVIEW MIRROR (OUTSIDE OF PASSENGER'S DOOR) PPL PWR SEAT CIRCUIT BREAKER 33 R MIRR SIG RED WIRE RED/WHT WIRE RIGHT SW SIG SERIAL DATA SPLICE TAN WIRE TILT/TELE SW/ MEM SEAT MOD FUSE 26 UP SW SIG VERTICAL MOTOR VERTICAL POSIT SENSOR LOW REFERENCE HORIZ POSIT SENSOR GROUND VERTICAL POSITION SENSOR HORIZONTAL MOTOR WHT WIRE YEL WIRE
