Cadillac XLR I (2003-2009) telescope forward ctrl telescope reverse ctrl tilt up ctrl tilt down ctrl Wiring diagram
This page shows the only wiring diagram for the component.telescope forward ctrl telescope reverse ctrl tilt up ctrl tilt down ctrl, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram telescope forward ctrl telescope reverse ctrl tilt up ctrl tilt down ctrl (1 of 1)
4.0 CM FROM SEAT ADJUSTER MOTOR ASSEMBLY BREAKOUT)
BATTERY (B+)
BLK WIRE
BODY CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER MEMORY SEAT MODULE (UNDER DRIVER'S SEAT)
EXIT SWITCH
GROUND
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (FRONT OF RIGHT FRONT FOOTWELL, BEHIND CARPET)
MEMORY 1 SWITCH
MEMORY SEAT SWITCH MEMORY 2 SWITCH
MEMORY SEATS CIRCUIT
NCA WIRE
ORG/ WIRE
OUT
PNK WIRE
PPL
PWR SEAT CIRCUIT BREAKER 33
RED WIRE
RED/WHT WIRE
TAN WIRE
TELESCOPE FORWARD CTRL TELESCOPE REVERSE CTRL TILT UP CTRL TILT DOWN CTRL
TELESCOPE IN
TELESCOPE OUT
TELESCOPING DRIVE MOTOR (LEFT SIDE OF STEERING COLUMN)
TILT ACTUATOR
TILT UP
TILT/ TELESCOPE SWITCH TILT DOWN
TILT/TELE SW/ MEM SEAT MOD FUSE 22
WHT WIRE
YEL WIRE
Go to component -> Steering column memory circuit -> TELESCOPE FORWARD CTRL TELESCOPE REVERSE CTRL TILT UP CTRL TILT DOWN CTRL
