Cadillac XLR I (2003-2009) stop/ b/u/lps fuse 5 Wiring diagrams
This page contains all the electrical diagrams for the component. stop/ b/u/lps fuse 5, in which he is found in the car Cadillac XLR I (2003-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stop/ b/u/lps fuse 5 (1 of 2)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION SHIFT LEVER
BACKUP LAMP RLY CTRL
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
CLASS 2 SER DATA
COMPUTER DATA LINES SYSTEM
GRN WIRE
GROUND
GRY WIRE
HI SPD SER DATA +
HI-SPEED GMLAN SER DATA BUS-
HOT AT ALL TIMES
HOT W/ RUN/ CRANK RELAY 7 ENERGIZED
INTERNAL MODE SWITCH (IMS) ASSEMBLY
LEFT BACKUP LAMP
LOGIC
LT GRN WIRE
NAVIGATION SYSTEM
ORG/BLK WIRE
PARK NEUTRAL SIGNAL
PARK/NEUTRAL SIGNAL
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
REVERSE LAMP RELAY 6
REVERSE LAMPS FUSE 9
RIGHT BACKUP LAMP
STOP/ B/U/LPS FUSE 5
TAN WIRE
TAN/BLK WIRE
TAP DWN -
TAP UP + TAP UP/ DOWN SWITCH
TAP UP/ DWN SW
TEHC MODULE ASSEMBLY
TRANSMISSION RANGE SIGNAL A
TRANSMISSION RANGE SIGNAL B
TUTD SW/ STRG COL SW FUSE 28
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Back-up lamps circuit -> STOP/ B/U/LPS FUSE 5
Wiring diagram stop/ b/u/lps fuse 5 (2 of 2)
55 56 38 CLASS 2 SER DATA RF TRN SIG VLT LF TRN SIG VLT
65 47 62 PRK LMP RLY CNTL LMP OUT DET SIG LMP OUT DET SIG PPL
9 5 67 66 HAZARD SW SIG PRK LMP SW ON SIG RT TRN SIG SW LT TRN SIG SW
AIR CONDITIONING SYSTEM
AMBIENT LIGHT SEN SIG
AUTOMATIC TRANSMISSION
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (BEHIND LOWER LEFT SIDE OF DASH)
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE (AT CENTER LOGIC HVAC CLASS SER DATA
LEFT FRONT MARKER LAMP
LEFT FRONT PARK LAMP
LEFT FRONT TURN SIGNAL LAMP
LOGIC
LOW REF
LOW REF BRK POS SENS SIG
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
OF DASH)
OFF AUTO
PARK HEAD
PARK LAMP RELAY 37
PARK LAMPS FUSE 8
PPL 7 8
RED WIRE
RED/WHT WIRE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK LAMP
RIGHT FRONT TURN SIGNAL LAMP
RR LMP SUPPLY VLT LR LMP SUPPLY VLT
STOP/ B/U/LPS FUSE 5
STP LMP SW SIG
SUNLOAD SENSOR ASSEMBLY
TAN WIRE
TEHC MODULE ASSEMBLY
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDER- HOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> STOP/ B/U/LPS FUSE 5
