Cadillac XLR I (2003-2009) power distribution, navigation systems power distribution, wiper/washer systems Wiring diagram
This page shows the only wiring diagram for the component.power distribution, navigation systems power distribution, wiper/washer systems, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power distribution, navigation systems power distribution, wiper/washer systems (1 of 1)
BACKUP LAMP SPLY VOL
BATT 3 FUSE 26
BATT 5 FUSE 7
BATTERY
BATTERY BATTERY
BATTERY BATTERY BATTERY
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
COURTESY LAMPS SUPPLY VOLTAGE FT PSNGR DR LATCH CTRL
DK GRN WIRE
DOOR LOCKS SYSTEM
DRVR DR LATCH CTRL
ELECTRONIC MUFFLERS SYSTEM
EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
EXTERIOR LIGHTS SYSTEM NAVIGATION SYSTEM (PARKING ASSIST CIRCUIT)
HOT AT ALL TIMES
IGN 1 VOLTAGE
IGN MODE SW SPLY VOL
INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM
LOGIC
LR STOP/TURN LAMP SUPPLY VOLTAGE COURTESY LAMP LOW CTRL
LT GRN WIRE
OF ENGINE COMPARTMENT)
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION, NAVIGATION SYSTEMS POWER DISTRIBUTION, WIPER/WASHER SYSTEMS
POWER DISTRIBUTION, SEATS SYSTEMS
POWER DISTRIBUTION, SHIFT INTERLOCK SYSTEMS (PARK BRAKE RELEASE CIRCUIT)
POWER DISTRIBUTION, TRANSMISSIONS SYSTEMS
RED/BLK WIRE
RED/WHT WIRE
RR STOP/TURN LAMP SUPPLY VOLTAGE
SOUND SYSTEMS POWER DISTRIBUTION SYSTEM COMPUTER DATA LINES SYSTEM
STOP/B/U LPS FUSE 5
TAN WIRE
UNDER- HOOD FUSE BLOCK (RIGHT REAR
YEL WIRE
Go to component -> Body control modules circuit (2 of 4) -> POWER DISTRIBUTION, NAVIGATION SYSTEMS POWER DISTRIBUTION, WIPER/WASHER SYSTEMS
