Cadillac XLR I (2003-2009) pnk (approximately 11 cm from yaw rate Wiring diagram

7 8 9 10 11 PPL BLK WIRE BLK/WHT WIRE BODY SCM/PSIR SW FUSE 13 CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH) BRN WIRE CASE GROUND CONNECTOR DK BLU WIRE DK GRN WIRE DRIVER SEAT BELT SWITCH GRN WIRE GRY WIRE HOT W/ RUN/ CRANK RELAY ENERGIZED INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER CENTER CONSOLE) INFLATABLE RESTRAINT STEERING WHEEL MODULE (CENTER OF STEERING WHEEL) INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LEFT FRONT SEAT BELT PRETENSIONER LEFT INFLATABLE RESTRAINT SIDE IMPACT MODULE (LEFT SIDE OF DRIVER'S SEAT BACK) LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER SEAT BELT SWITCH PNK (APPROXIMATELY 11 CM FROM YAW RATE WIRE PNK 1 2 3 WIRE PNK PNK WIRE PNK SHORTING BAR WIRE PNK WIRE PPL RIGHT FRONT SEAT BELT PRETENSIONER RIGHT INFLATABLE RESTRAINT SEAT POSITION SWITCH (IN RIGHT FRONT SEAT TRACK) RIGHT INFLATABLE RESTRAINT SIDE IMPACT MODULE (RIGHT SIDE OF PASSENGER'S SEAT) SERIAL DATA SHORTING BAR STAGE 1 STAGE 2 TAN WIRE TAN/WHT WIRE WHT WIRE YEL WIRE YEL/BLK WIRE
