Cadillac XLR I (2003-2009) passenger climate control seat module front passenger seat pump Wiring diagram

ADAPTIVE CRUISE MODULE (ACM) AUTOMATIC TRANSMISSION SHIFT LEVER AUXILIARY POWER OUTLET AUXILIARY POWER RELAY BLK WIRE BLOWER MOTOR CONTROL PROCESSOR BODY CONTROL MODULE (BCM) BRAIDED CIGAR LIGHTER CONSOLE COURTESY LAMP SWITCH FRONT PASSENGER DOOR LOCK SWITCH FRONT PASSENGER DOOR MODULE (FPDM) FRONT PASSENGER SEAT ADJUSTER SWITCH FRONT PASSENGER WINDOW SWITCH GARAGE DOOR OPENER HVAC CONTROL MODULE I/P COMPARTMENT LAMP INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) INSIDE REARVIEW MIRROR LEFT VANITY MIRROR LAMP NCA WIRE OUTSIDE MOISTURE SENSOR PARK BRK HOLD RELAY PARK BRK RELEASE RELAY PASSENGER CLIMATE CONTROL SEAT MODULE FRONT PASSENGER SEAT PUMP PASSENGER DOOR LOCK INDICATOR PASSENGER EXTERIOR DOOR HANDLE SWITCH PASSENGER INTERIOR DOOR HANDLE SWITCH PASSENGER OUTSIDE REARVIEW MIRROR REAR COMPARTMENT LID PULLDOWN ACTUATOR FRONT PASSENGER DOOR LATCH REAR OBJECT SENSOR CONTROL MODULE RIGHT TAIL LAMP ASSEMBLY RIGHT DOOR COURTESY LAMP RIGHT VANITY MIRROR LAMP SPLICE PACK TRACTION CONTROL SWITCH VALET SWITCH WHT WIRE
