Cadillac XLR I (2003-2009) park brake release solenoid Wiring diagram
This page shows the only wiring diagram for the component.park brake release solenoid, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park brake release solenoid (1 of 1)
49 PNK WIRE
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DECK LID CLOSE/ PARK/BRK B FUSE 32
HOT AT ALL TIMES
I/P RELAY BLOCK (FRONT OF RIGHT FRONT FOOTWELL, BEHIND CARPET)
INSTRUMENT PANEL CLUSTER (IPC) PARK BRAKE SWITCH SIGNAL
LOGIC PARK BRAKE RELAY 1 CTRL
LT BLU WIRE
LT GRN WIRE
PARK BRAKE HOLD SOLENOID
PARK BRAKE PEDAL ASSEMBLY
PARK BRAKE RELAY 1 CTRL
PARK BRAKE RELEASE SOLENOID
PARK BRAKE SOL A FUSE 8
PARK BRAKE SWITCH
PARK BRK HOLD RELAY
PARK BRK RELEASE RELAY
POWER DISTRIBUTION SYSTEM
RED WIRE
TAN WIRE
WHT WIRE
Go to component -> Park brake release circuit -> PARK BRAKE RELEASE SOLENOID
