Cadillac XLR I (2003-2009) mrrtd fuse 13 ecm/ tcm fuse 11 Wiring diagram
This page shows the only wiring diagram for the component.mrrtd fuse 13 ecm/ tcm fuse 11, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mrrtd fuse 13 ecm/ tcm fuse 11 (1 of 1)
A/C COMP CLUTCH RLY CTRL
ACC VOL IGN 1 VLT BATTERY + VLT PNK WIRE
ACCELERATOR PEDAL POSITION (APP) SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
AIR CONDITIONING SYSTEM
APP SENS 1 SIG FUEL TANK PRESS SENS SIG APP SENS 2 SIG
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (ECM) (LOWER RIGHT REAR OF ENGINE COMPT)
ENGINE SPEED SIG
ETC FUSE 9
EVAP CANISTER VENT SOL CTRL STARTER ENABLE RLY CTRL
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID
FUEL LVL SENS PRI FUEL LVL SENS SEC
GRY WIRE
HOT AT ALL TIMES
IGN 1 RELAY 44
LOW REF
LOW REF LOW REF PPL
LT BLU WIRE
MIL CTRL FUEL PUMP RLY CTRL
MRRTD FUSE 13 ECM/ TCM FUSE 11
PNK 3 4 WIRE
PNK PNK 6 7 WIRE
PNK WIRE
PPL
RED/WHT WIRE
STARTING/ CHARGING SYSTEM
STOP LAMP SW SIG
TAN WIRE
TO EMISSION FUSE 14 (DIAGRAM 4 OF 6)
TRANSMISSIONS SYSTEM
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
VEHICLE SPEED SIG IGNITION 1 RLY CTRL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 4.6l vin a (1 of 6) -> MRRTD FUSE 13 ECM/ TCM FUSE 11
