Cadillac XLR I (2003-2009) left amber ind center amber ind ind Wiring diagram

ASSIST CHIME SIG BACKUP LAMP SPLY VOLTAGE REAR PARKING DIAGNOSTIC SIG BLK WIRE BODY CONTROL MODULE (BCM) BREAKOUT) CENTER AMBER IND CTRL LEFT AMBER IND CTRL DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (LOWER RIGHT REAR OF ENGINE COMPT) GROUND IGN 1 VOLTAGE PNK WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER SYSTEM LEFT AMBER IND CENTER AMBER IND IND LEFT REAR CORNER OBJECT SENSOR (LEFT CORNER OF REAR BUMPER) LEFT REAR MIDDLE OBJECT SENSOR (LEFT MIDDLE OF REAR BUMPER) LOGIC LR CORNER OBJECT SENS SIG LR MIDDLE OBJECT SENS SIG LT GRN WIRE OBJECT SENS LOW REF OBJECT SENS SPLY VOLTAGE ORG/ WIRE PNK PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL RR CORNER OBJECT SENS SIG REAR OBJECT SENSOR CONTROL MODULE (BEHIND REAR COMPARTMENT STOWAGE TRIM PANEL) REAR PARKING REAR PARKING ASSIST (RPA) DIAGNOSTIC CONNECTOR REAR PARKING ASSIST (RPA) DISPLAY REAR PARKING ASSIST CHIME SIG TELLTALE ASSEMBLY SPLY VOLTAGE RED IND CRTL WIRE RED WIRE REVERSE LAMP REVERSE LAMP RELAY 6 REVERSE LAMPS FUSE 9 RIGHT REAR CORNER OBJECT SENSOR (RIGHT CORNER OF REAR BUMPER) RIGHT REAR MIDDLE OBJECT SENSOR (RIGHT MIDDLE OF REAR BUMPER) RLY CTRL RPA/ H/C SEAT/WIPR RELAYS FUSE 14 RR MIDDLE OBJECT SENS SIG RUN/ CRANK RELAY 7 RUN/CRANK SPICE PACK UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT) VEHICLE SPEED SIG WHT WIRE YEL WIRE
