Cadillac XLR I (2003-2009) iss signal battery pos volt oss signal Wiring diagram
This page shows the only wiring diagram for the component.iss signal battery pos volt oss signal, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram iss signal battery pos volt oss signal (1 of 1)
ACC/TCM FUSE 3
ACCESSORY VOLTAGE DATA BUS - DATA BUS + IGNITION 1 VOLTAGE DATA BUS + DATA BUS -
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
ECM/TCM FUSE 11
GEAR HIGH TRANS TEMP SERVICE TRANS SHIFT TO PRK
GMLAN (ECM)
GRN WIRE
GRY WIRE
HEADS UP DISPLAY (HUD) (TOP LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN RUN OR START
HUD CLASS 2 SERIAL DATA
HUD MESSAGE CENTER
IN SPEED SENSOR SIG BATTERY POSITIVE VOLT OUT SPEED SENSOR SIG
INPUT/OUTPUT SPEED SENSORS (ISS/OSS) ASSEMBLY
INSTRUMENT PANEL CLUSTER (IPC)
INTERNAL MODE SWITCH (IMS) ASSEMBLY
IPC CLASS 2 SERIAL DATA
ISS SIGNAL BATTERY POS VOLT OSS SIGNAL
LOGIC
MESSAGE CENTER
MESSAGE REQUEST (TCM)
NCA WIRE
ORG/BLK WIRE
PARK/NEUTRAL SIG BATTERY POS VOLT GROUND STOP LAMP SW SIG TAP UP/DN SW SIG
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RED/WHT WIRE
TAN WIRE
TAN/BLK WIRE
TAP UP/DWN GEAR
TEHC MODULE ASSEMBLY
UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT)
UP SHIFT IND
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> A/t circuit (1 of 2) -> ISS SIGNAL BATTERY POS VOLT OSS SIGNAL
