Cadillac XLR I (2003-2009) hi-speed gmlan ser data bus- Wiring diagram
This page shows the only wiring diagram for the component.hi-speed gmlan ser data bus-, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi-speed gmlan ser data bus- (1 of 1)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION SHIFT LEVER
BACKUP LAMP RLY CTRL
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
CLASS 2 SER DATA
COMPUTER DATA LINES SYSTEM
GRN WIRE
GROUND
GRY WIRE
HI SPD SER DATA +
HI-SPEED GMLAN SER DATA BUS-
HOT AT ALL TIMES
HOT W/ RUN/ CRANK RELAY 7 ENERGIZED
INTERNAL MODE SWITCH (IMS) ASSEMBLY
LEFT BACKUP LAMP
LOGIC
LT GRN WIRE
NAVIGATION SYSTEM
ORG/BLK WIRE
PARK NEUTRAL SIGNAL
PARK/NEUTRAL SIGNAL
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
REVERSE LAMP RELAY 6
REVERSE LAMPS FUSE 9
RIGHT BACKUP LAMP
STOP/ B/U/LPS FUSE 5
TAN WIRE
TAN/BLK WIRE
TAP DWN -
TAP UP + TAP UP/ DOWN SWITCH
TAP UP/ DWN SW
TEHC MODULE ASSEMBLY
TRANSMISSION RANGE SIGNAL A
TRANSMISSION RANGE SIGNAL B
TUTD SW/ STRG COL SW FUSE 28
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Back-up lamps circuit -> HI-SPEED GMLAN SER DATA BUS-
