Cadillac XLR I (2003-2009) hdlp wash relay 46 fog lp relay 38 Wiring diagram
This page shows the only wiring diagram for the component.hdlp wash relay 46 fog lp relay 38, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hdlp wash relay 46 fog lp relay 38 (1 of 1)
A/C COMP FUSE 15
A/C COMP RELAY 35
ABS FUSE 27
AMP FUSE 31
AUDIO AMPLIFIER
AUTOMATIC TRANSMISSION
BATT 1 FUSE 33
BATT 2 FUSE 29
BATTERY
BLK WIRE
BLOWER MOTOR CONTROL PROCESSOR
COOLFAN FUSE 25
CRANK RELAY 43
DR CNTRLS CIRCUIT BREAKER 34
DRIVER CLIMATE CONTROL SEAT MODULE DRIVER UPPER LUMBAR SWITCH
DRIVER DOOR MODULE (DDM) FRONT PASSENGER DOOR MODULE (FPDM)
DRIVER LOWER LUMBAR SWITCH
DRIVER MEMORY SEAT MODULE
DRIVER SEAT PUMP
ECM/TCM FUSE 11
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ELECTRONIC SUSPENSION CONTROL (ESC) MODULE
ENGINE CONTROL MODULE (ECM)
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID
FAN CONTROL MODULE
FOLDING TOP MODULE
FRONT PASSENGER SEAT PUMP
FUEL DOOR RELAY 52
FUSIBLE LINK
GENERATOR
HDLP WASH FUSE 18 FOG LP FUSE 22
HDLP WASH RELAY 46 FOG LP RELAY 38
HIGH BEAM RELAY 39
HORN FUSE 2
HORN RELAY 34
HVAC FUSE 28
I/P RELAY BLOCK (FRONT OF RIGHT FRONT FOOTWELL, BEHIND CARPET)
IGN 1 RELAY 44
LEFT HEATED SEAT FUSE 42
LEFT/RIGHT POWER LUMBAR FUSE 40
LOW BEAM RELAY 47
MRRTD FUSE 13
NCA WIRE
PARK LAMP RELAY 37
PASSENGER LOWER LUMBAR SWITCH
PK LAMPS FUSE 8
POWER SEATS CIRCUIT BREAKER 33
REAR DEFOG RELAY 40
RED WIRE
RED/BLK WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT HEATED SEAT FUSE 41
STARTER
STARTER FUSE 30
TECH MODULE ASSEMBLY
TO AUXILIARY POWER RELAY (DIAGRAM 3 OF 4)
TO BATT 3 FUSE 26 (DIAGRAM 2 OF 4)
W/S WASH RELAY 36
W/S WASH/ INTERCOOL FUSE 17
WHT WIRE
WIPER FUSE 4
WIPER ON/OFF RELAY 45
WIPER RUN/ACC RELAY 42
Go to component -> Power distribution circuit (1 of 4) -> HDLP WASH RELAY 46 FOG LP RELAY 38
