Cadillac XLR I (2003-2009) back-up keyless entry antenna Wiring diagram
This page shows the only wiring diagram for the component.back-up keyless entry antenna, which is found in the car Cadillac XLR I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back-up keyless entry antenna (1 of 1)
BACK-UP KEYLESS ENTRY ANTENNA
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
BRN WIRE
DK BLU WIRE
FROM BODY CONTROL MODULE (DIAGRAM 3 OF 4)
IGN DATA SIG GND IGN 1 VOLTAGE
IGNITION MODE SWITCH
IND
LEFT KEYLESS ENTRY ANTENNA
LOGIC
LOW REF BACK UP SIG LOW REF SIG LOW REF RIGHT SIG LOW REF LEFT SIG
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
OFF IND IND
OFF ON
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
PPL
REAR COMPARTMENT KEYLESS ENTRY ANTENNA
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (BEHIND RIGHT SIDE OF DASH)
RIGHT KEYLESS ENTRY ANTENNA
TAN WIRE
WHT WIRE
Go to component -> Power distribution circuit (4 of 4) -> BACK-UP KEYLESS ENTRY ANTENNA
