Cadillac XLR I (2003-2009) auxiliary power relay coil supply voltage Wiring diagram

AUXILIARY POWER RELAY (BEHIND RIGHT SIDE OF DASH) AUXILIARY POWER RELAY COIL SUPPLY VOLTAGE BATT 1 FUSE 33 BLK WIRE BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH) BRN WIRE DECK LID CLOSE/ PRK/BRK B FUSE 32 DK BLU WIRE FOLDING TOP CLOSED SWITCH (TOP OF RIGHT "A" PILLAR) FOLDING TOP PUMP MOTOR FOLDING TOP PUMP, VALVE ASSEMBLY (LEFT SIDE OF FOLDING TOP STORAGE COMPARTMENT) GRN WIRE GRY WIRE GRY/BLK WIRE HEADER LATCH SWITCH HEADER UNLATCH SWITCH HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE LUGGAGE BARRIER SWITCH NCA WIRE PNK PPL 1 2 WIRE PNK WIRE PPL REAR COMPARTMENT LID OPEN SWITCH REAR COMPARTMENT LID PULLDOWN ACTUATOR (AT UPPER CENTER OF LUGGAGE COMPT) RED WIRE RED/BLK WIRE RED/WHT WIRE SPLICE PACK TAN WIRE TAN/WHT WIRE THERMAL TILT/TELE SW/MEM SEAT MOD FUSE 22 UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT) VALVE 1 VALVE 2 VALVE 3 VALVE 4 VALVE 5 WHT WIRE YEL WIRE
