Cadillac XLR I (2003-2009) abs/mrrtd/afs fuse 1 Wiring diagram

6.5 CM FROM BREAK OUT TO ACCELERATOR PEDAL POSITION SENSOR) ABS FUSE 27 ABS/MRRTD/AFS FUSE 1 ACCELEROMETER LATERAL BAT BAT IGN 1 VOLTAGE BLK WIRE BLK/WHT WIRE BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR) BRAKE FLUID PRESSURE SENSOR (ON BRAKE PRESSURE MODULATOR VALVE) BRAKE IND BRK FLUID LVL SENS SIGNAL BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT FRONT OF ENGINE COMPT) ELECTRONIC POWER STEERING SYSTEM GMLAN GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGN INSTRUMENT PANEL CLUSTER (IPC) IPC IPC CLASS 2 SERIAL DATA LEFT FRONT WHEEL SPEED SENSOR (AT LEFT FRONT HUB ASSEMBLY) LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR HUB ASSEMBLY) LOGIC LOW REF LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MESSAGE CENTER MESSAGE REQUEST ORG/ WIRE PNK PNK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL RED WIRE RED/BLK WIRE RIGHT FRONT WHEEL SPEED SENSOR (AT RIGHT FRONT HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR HUB ASSEMBLY) SENS SIG SENSOR STEERING ANGLE SENSOR STRNG WHEEL POS SIG A STRNG WHEEL POS SIG B TAN WIRE TAN/BLK WIRE TO BRAKE PRESSURE MODULATOR VALVE (DIAGRAM 2 OF 2) TRACTION CONTROL IND ABS IND UNDERHOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT) WHT WIRE YAW RATE YAW, LATERAL ACCELEROMETER SENSOR (BEHIND CENTER OF DASH) YEL WIRE
