Cadillac XLR I (2003-2009) 19 12 class 2 ser data htd mirror elmnt pwr Wiring diagram

19 12 CLASS 2 SER DATA HTD MIRROR ELMNT PWR 19 2 CLASS 2 SER DATA HTD MIRROR ELMNT PWR BATT 2 FUSE 29 BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DEFOG CTRL CLASS 2 SER DATA DEFOGGER SWITCH DK GRN WIRE DRIVER DOOR MODULE (DDM) (IN DRIVER'S DOOR) DRIVER OUTSIDE REARVIEW MIRROR (OUTSIDE OF DRIVER'S DOOR) FRONT PASSENGER DOOR MODULE (FPDM) (IN FRONT DOOR) HEATED MIRROR ELEMENT HOT AT ALL TIMES HVAC CONTROL MODULE (AT CENTER OF DASH) IGN DEFOG RLY CTRL LOGIC NCA WIRE ORG/ WIRE PASSENGER OUTSIDE REARVIEW MIRROR (OUTSIDE OF PASSENGER'S DOOR) REAR DEFOG RELAY 40 REAR WINDOW REAR WINDOW DEFOGGER GRID RED WIRE TAN WIRE UNDER- HOOD FUSE BLOCK (RIGHT REAR OF ENGINE COMPT) WHT WIRE
