Wiper/washer circuit, without wiper inhibit system for Cadillac STS I facelift (2007-2011)

1 11 20 24 ACC VOLT WIPER SW SIGNAL 2 WIPER SW ON SIGNAL HDLP RELAY CONTROL ACCY RELAY BLK WIRE BRN WIRE DK BLU WIRE GRY WIRE HOT AT ALL TIMES HOT W/ RUN/CRANK RELAY ENERGIZED HTD WASH/AQS FUSE INSTRUMENT PANEL MODULE (IPM) (RIGHT SIDE OF DASH, BEHIND GLOVE BOX) LEFT HEATED WASHER NOZZLE LT GRN WIRE ORG/ WIRE PNK WIRE PPL RAIN SNSR/TPM FUSE RIGHT HEATED WASHER NOZZLE (IF EQUIPPED) TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPT) W/ HID (W/ TIRE PRESSURE) WASHER FLUID LEVEL SIG WASHER SWITCH WHT WIRE WINDSHIELD WIPER/ WASHER MODULE (LEFT REAR OF ENGINE COMPT, NEAR WINDSHIELD) WINDSHIELD WIPER/WASHER SWITCH WIPER SWITCH WPR FUSE WPR HI RELAY WPR/SW/VICS FUSE YEL WIRE

4 3 2 1 ACC VOLT GROUND SNS SIG 1 SNS SIG 2 BLK WIRE FLUID RESERVOIR) HDLP WASH CIRCUIT BREAKER HEADLAMP WASHER FLUID PUMP (INSIDE WASHER HEADLAMP WASHER FLUID PUMP RELAY (W/ HIGH PRESSURE HEADLAMP WASHER) (MOUNTED TO CORE SUPPORT, IN FRONT OF UNDERHOOD FUSE BLOCK) HOT AT ALL TIMES LT GRN WIRE ORG/ WIRE PPL RED WIRE RED/BLK WIRE TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPT) WHT WIRE WINDSHIELD OUTSIDE MOISTURE SENSOR (IF EQUIPPED) (BEHIND INSIDE REARVIEW MIRROR) WINDSHIELD WASHER FLUID LEVEL SWITCH (IN WASHER FLUID RESERVOIR) WINDSHIELD WASHER FLUID PUMP (ON SIDE OF WINDSHIELD WASHER RESERVOIR) YEL WIRE
