Lane departure warning circuit for Cadillac STS I facelift (2007-2011)
Lane departure warning circuit
BATTERY POSITIVE VOLT
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC)
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LANE DEPARTURE IND
LOGIC LEFT TURN IND
LOW SPD GMLAN SERIAL DATA
LT TRN/ LDW FUSE
RADIO
RED/BLK WIRE
RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT)
RIGHT TURN IND
VEHICLE DIRECTION ALERT ALARM WARNING MODULE (IN REAR COMPARTMENT)
