Cadillac STS I facelift (2007-2011) Shift interlock circuit

4.6L 3.6L A/T SHIFT LOCK CTRL SOLENOID AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) AUTOMATIC TRANSMISSION SHIFT LEVER BRAKE PEDAL POSITION SENSOR (ATTACHED TO TOP OF BRAKE PEDAL ASSEMBLY) BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK GRN WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL MODULE (IPM) LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT) LOGIC LOW REF NCA WIRE ORG/BLK WIRE P/N SIG RED WIRE RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (UNDER REAR SPEAKER SHELF) SENS SIG SERIAL DATA SHIFT LOCK CONTROL SHIFT PARK SUPPLY VOLTAGE SHIFT PARK SIGNAL THEFT/ SHFT FUSE TRANSMISSION CONTROL MODULE (TCM) GROUND WHT WIRE YEL WIRE YEL/BLK WIRE
