Courtesy lamps circuit for Cadillac STS I (2004-2007)

BLK WIRE COMPUTER DATA LINES SYSTEM CTSY LMP CTRL CTSY LMP SUPPLY CTSY RELAY CTRL DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE FRONT OVERHEAD COURTESY/ READING LAMPS GMLAN SERIAL DATA GRY WIRE HOT AT ALL TIMES I/P COMPART- MENT LAMP I/P COMPART- MENT LAMP/ SWITCH INTERIOR LAMP FUSE INTERIOR LAMP RELAY LEFT FOOTWELL COURTESY LAMP LEFT REAR DOOR COURTESY LAMP LEFT VANITY MIRROR LAMP ORG/ WIRE PPL REAR COMPART- MENT COURTESY LAMP REAR COMPART- MENT LID RELEASE ACTUATOR REAR INTEGRATION MODULE (RIM) (LEFT SIDE OF REAR COMPT) REAR OVERHEAD COURTESY/ READING LAMPS RIGHT FOOTWELL COURTESY LAMP RIGHT REAR DOOR COURTESY LAMP RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT) RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT) TRUNK DIODE RIGHT VANITY MIRROR LAMP SPLICE PACK WHT WIRE

AJAR AUTO ON BLK WIRE COMPUTER DATA LINES SYSTEM COURTESY LAMP HIGH COURTESY LAMP LOW COURTESY LAMP SW ON DK GRN WIRE DRIVER DOOR MODULE (DDM) (IN DOOR) FRONT PASSENGER DOOR MODULE (FPDM) (IN DOOR) GMLAN SERIAL DATA GRY WIRE GRY/BLK WIRE I/P DIMMER SW LOW I/P DIMMER SWITCH INSTRUMENT PANEL MODULE (IPM) (BEHIND RIGHT SIDE OF DASH) LEFT FRONT DOOR COURTESY LAMP LEFT FRONT DOOR LATCH ASSEMBLY LEFT REAR DOOR MODULE (LRDM) (IN DOOR) LF DOOR AJAR LR DOOR AJAR LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE PNK/BLK WIRE PPL/WHT WIRE RF DOOR AJAR RIGHT FRONT DOOR COURTESY LAMP RIGHT FRONT DOOR LATCH ASSEMBLY RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR DOOR MODULE (RRDM) (IN DOOR) RR DOOR AJAR TAN WIRE TAN/WHT WIRE WHT WIRE
