Cadillac STS I (2004-2007) windshield wiper/ washer module Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper/ washer module, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper/ washer module (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
ACCESSORY RELAY
BLK WIRE
BRN WIRE
CCP FUSE
COMP CLUTCH FUSE
DISTANCE SENSING CRUISE CONTROL MODULE (W/ AUTO ADAPTIVE CRUISE CONTROL)
FOG LAMP FUSE
FOG LAMP RELAY
FROM INSTRUMENT PANEL MODULE (DIAGRAM 4 OF 7)
FROM UNDERHOOD FUSE BLOCK (MAIN RELAY) (DIAGRAM 1 OF 7)
HDLP WASHER CIRCUIT BREAKER
HEAD UP DISPLAY (HUD)
HEADLAMP LEVELING MODULE
HEADLAMP WASHER FLUID PUMP FLUID
HEADLAMP WASHER FLUID PUMP RELAY
HIGH BEAM RELAY
HORN FUSE
HORN RELAY
HUD FUSE
HVAC CONTROL MODULE
L REAR FUSE
LOW BEAM RELAY
PARK LAMP RELAY
R REAR FUSE
RAIN SENSOR HDLP FUSE
RED WIRE
SPARE FUSE
SPARE RELAY
TILT/ TELESCOPE SWITCH
TILT/LK LMP/CLM RELAY COILS FUSE
TO LEFT REAR FUSE BLOCK (ALC RELAY
TO LEFT REAR FUSE BLOCK (DRIVER DOOR MODULE
TO RIGHT REAR FUSE BLOCK (IGN 1 RELAY) (DIAGRAM 7 OF 7)
TO RIGHT REAR FUSE BLOCK (POWER WINDOWS MOTOR CIRCUIT
W/ HID HEADLAMPS
WHT WIRE
WINDSHIELD WIPER/ WASHER MODULE
WPR MOD FUSE
WPR SW VICS FUSE SPARE FUSE
YEL WIRE
Go to component -> Power distribution circuit (2 of 7) -> WINDSHIELD WIPER/ WASHER MODULE
