Cadillac STS I (2004-2007) tpm indicator cruise indicator Wiring diagram
This page shows the only wiring diagram for the component.tpm indicator cruise indicator, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tpm indicator cruise indicator (1 of 1)
ABS INDICATOR
BACKLIGHTING
BACKLIGHTING CTRL
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH (MASTER CYLINDER RESERVOIR)
BRAKE INDICATOR
BRN WIRE
BRN/WHT WIRE
CHARGE INDICATOR SECURITY INDICATOR
CLASS 2 (ECM)
CLASS 2 (IPM)
CLOCK
CLOCK CTRL
DIC SW
DIC SW SIG DIC SW LOW REF
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM/TCM FUSE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE INDICATOR
FASTEN SAFETY BELT INDICATOR
FRONT FOG LAMPS INDICATOR
FUEL LEVEL
GMLAN (EBCM)
GMLAN (ECM)
GMLAN (ECM) GMLAN
GMLAN (ECM) GMLAN (RIM)
GMLAN (IPM)
GMLAN (RIM)
GMLAN (SDM)
GMLAN (TCM)
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN RUN OR START
HUD FUSE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT TURN INDICATOR
LIGHTS ON INDICATOR
LOW ENGINE OIL PRESSURE INDICATOR
MALFUNCTION INDICATOR
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RED/WHT WIRE
RIGHT TURN INDICATOR
SIR INDICATOR
SPEEDOMETER
SPORT MODE INDICATOR
TACHOMETER
TAP UP/ DOWN ENABLE INDICATOR
TCM/IPC/ ECM FUSE
TEMPERATURE
TPM INDICATOR CRUISE INDICATOR
TRACTION CONTROL OFF INDICATOR
TRIP ODOMETER
TRIP RESET SW SIG
TRIP RESET SWITCH
TRIP/ODOMETER CTRL
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENG COMPT)
WAIT TO START INDICATOR (NOT USED)
WHT WIRE
WINTER MODE INDICATOR
Go to component -> Instrument cluster circuit (1 of 2) -> TPM INDICATOR CRUISE INDICATOR
