Cadillac STS I (2004-2007) steer wheel pos sig b low ref Wiring diagram
This page shows the only wiring diagram for the component.steer wheel pos sig b low ref, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steer wheel pos sig b low ref (1 of 1)
ABS FUSE
BLK WIRE
BLU WIRE
BRAKE FLUID PRESSURE SENSOR (ON REAR OF EBCM)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
EBCM FUSE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON RIGHT FRONT CORNER OF ENGINE COMPT)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGN 1 RELAY
LONG ACCELEROMETER SIGNAL
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT LT
PNK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
STEER WHEEL POS SIG A
STEER WHEEL POS SIG B LOW REF
STEERING ANGLE SENSOR (ON BASE OF
STEERING COLUMN)
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPT)
WHT WIRE
YAW RATE, LATERAL ACCELERATION SENSOR (UNDER FRONT PASSENGER SEAT)
Go to component -> Electronic power steering circuit -> STEER WHEEL POS SIG B LOW REF
