Cadillac STS I (2004-2007) standing lamp relay wiring diagram
This page shows the only wiring diagram for the component.standing lamp relay, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
standing lamp relay wiring diagram (1 of 1)
A/T SHIFT SHIFT LEVER ASSEMBLY
AIRBAG FUSE
ALC RELAY FUSE
AMP FUSE
AUDIO AMPLIFIER
AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR
AUTOMATIC LEVELING CONTROL (ALC) COMPRESSOR RELAY
BLK WIRE
DPM FUSE
DRIVER ADJUSTER SEAT SWITCH DRIVER CUSHION COOLED SEAT BLOWER MOTOR
DRIVER BACK COOLED SEAT BLOWER MOTOR REAR SUBWOOFER SPEAKER
DRIVER DOOR MODULE (DDM)
DRIVER DOOR MODULE FUSE
DRIVER LUMBAR ADJUSTER SWITCH
ELC SOLENOID FUSE
ELECTRONIC SUSPENSION CONTROL (ESC) MODULE
ELECTRONICS SUSPENSION CONTROL (ESC) MODULE FUSE
FROM UNDERHOOD FUSE BLOCK
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
JOINT CONNECTOR
LEFT FRONT DOOR SUBWOOFER SPEAKER
LEFT POSITION LAMP RELAY
LEFT REAR DOOR MODULE (LRDM)
LEFT REAR FUSE BLOCK (IGN 3 RELAY) (DIAGRAM 6 OF 7)
MEMORY SEAT MODULE (MSM)
NCA WIRE
POSITION LAMPS FUSE
REAR DOOR MODULE FUSE
REAR SPEAKER (SUBWOOFER) FUSE
RED WIRE
REV LAMP RELAY
REVERSE LAMP FUSE
RIGHT POSITION LAMP RELAY
RIGHT REAR DOOR MODULE (RRDM)
SPARE FUSE
SPLICE PACK
STANDING LAMP RELAY
THEFT/ SHIFTER FUSE
TRK DR REL SOL RELAY
TRUNK DOOR/ VALET FUSE
TV ANTENNA MODULE
TV/VICS FUSE
W/ INFOTAINMENT SYSTEM 010
W/ INFOTAINMENT SYSTEM 012, 014, 015
WHT WIRE
Go to component -> Power distribution circuit (5 of 7) -> STANDING LAMP RELAY
