Cadillac STS I (2004-2007) power seat circuit breaker Wiring diagrams
This page contains all the electrical diagrams for the component. power seat circuit breaker, in which he is found in the car Cadillac STS I (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power seat circuit breaker (1 of 2)
BATTERY
BLK WIRE
BLU WIRE
DOWN
HORIZONTAL
HOT AT ALL TIMES
LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT)
LUMBAR MOTOR DOWN CONTROL
LUMBAR MOTOR FORWARD CONTROL
LUMBAR MOTOR REARWARD CONTROL
LUMBAR MOTOR UP CONTROL
ORG/ WIRE
PASSENGER LUMBAR ADJUSTER SWITCH
PASSENGER LUMBAR MOTOR ASSEMBLY
PNK WIRE
POWER SEAT CIRCUIT BREAKER
RED/WHT WIRE
RWD
VERTICAL
W/ HEATED SEATS
WHT WIRE
Go to component -> Passenger"s lumbar circuit -> POWER SEAT CIRCUIT BREAKER
Wiring diagram power seat circuit breaker (2 of 2)
BATTERY
BLK WIRE
BLU WIRE
DOWN
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR
DRIVER SEAT RECLINE MOTOR
FRONT VERTICAL DOWN
FRONT VERTICAL UP
GRN WIRE
HORIZONTAL FORWARD
HORIZONTAL REARWARD
HOT AT ALL TIMES
LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT)
MEMORY FUSE
NCA WIRE
PASSENGER SEAT ADJUSTER MOTOR ASSEMBLY
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT FRONT VERTICAL MOTOR
PASSENGER SEAT HORIZONTAL MOTOR
PASSENGER SEAT REAR VERTICAL MOTOR
PASSENGER SEAT RECLINE MOTOR
POWER SEAT CIRCUIT BREAKER
REAR
REAR VERTICAL DOWN
REAR VERTICAL UP
RECLINE FORWARD
RECLINE REARWARD
RED/WHT WIRE
TAN WIRE
W/ HEATED SEATS
YEL WIRE
Go to component -> Power seats circuit -> POWER SEAT CIRCUIT BREAKER
