Cadillac STS I (2004-2007) passenger mirror motor horiz/ver ctrl Wiring diagram
This page shows the only wiring diagram for the component.passenger mirror motor horiz/ver ctrl, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger mirror motor horiz/ver ctrl (1 of 1)
7 2 14 3 9 CLASS 2 SERIAL DATA BATTERY CLASS 2 SERIAL DATA BATTERY GROUND
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN/WHT WIRE
CLASS 2
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DOWN MIRROR SWITCH SIG
DRIVER DOOR MODULE (ON DRIVER DOOR, UNDER DOOR TRIM PANEL)
DRIVER DOOR SWITCH ASSEMBLY
DRIVER DR MOD FUSE
DRIVER MIRROR MOTOR HORIZONTAL CTRL
DRIVER MIRROR MOTOR HORIZONTAL/VER CTRL
DRIVER MIRROR MOTOR VERTICAL CTRL
DRIVER OUTSIDE REARVIEW MIRROR
FRONT PASSENGER DOOR MODULE (ON FRONT PASSENGER DOOR, UNDER DOOR TRIM PANEL)
GROUND
GRY WIRE
HORIZ MOTOR
HOT AT ALL TIMES
LEFT
LEFT MIRROR SELECT
LEFT REAR FUSE BLOCK (NEAR LEFT SIDE OF REAR SEAT, UNDER CARPET)
LOGIC
PASSENGER MIRROR MOTOR HORIZ/VER CTRL
PASSENGER MIRROR MOTOR HORIZONTAL CTRL
PASSENGER OUTSIDE REARVIEW MIRROR
PPL
PPL PASSENGER MIRROR MOTOR VERTICAL CTRL
RED WIRE
RED/WHT WIRE
RIGHT
RIGHT MIRROR SELECT SWITCH SIG
RIGHT MIRROR SWITCH SIG LEFT MIRROR SWITCH SIG
RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET)
RT FRT DR MOD FUSE
SEL
SERIAL DATA
SWITCH SIG
UP MIRROR SWITCH SIG
VERT MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> PASSENGER MIRROR MOTOR HORIZ/VER CTRL
