Cadillac STS I (2004-2007) overhead courtesy/ front reading lamps Wiring diagram
This page shows the only wiring diagram for the component.overhead courtesy/ front reading lamps, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead courtesy/ front reading lamps (1 of 1)
AUDIO AMPLIFIER
AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR
BLK WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
COIL COIL COIL
DIGITAL RADIO RECEIVER
ELECTRONIC SUSPENSION CONTROL MODULE
EXTERIOR REAR COMPARTMENT LID RELEASE SWITCH
FUEL PUMP RELAY STOP LAMP RELAY IGN 1 RELAY
FUEL PUMP, SENDER ASSEMBLY
IGN-3 RELAY
LEFT BACKUP LAMP RIGHT BACKUP LAMP
LEFT LICENSE LAMP RIGHT LICENSE LAMP
LEFT REAR CORNERING/ SIDE MARKER LAMP
LEFT VANITY MIRROR LAMP
OVERHEAD COURTESY/ FRONT READING LAMPS
OVERHEAD COURTESY/ REAR READING LAMPS
REAR COMPARTMENT LID RELEASE ACTUATOR
REAR INTEGRATION MODULE (RIM)
REAR OBJECT SENSOR CONTROL MODULE
REAR SUBWOOFER SPEAKER
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT REAR CORNERING/ SIDE MARKER LAMP
RIGHT TAIL LAMP ASSEMBLY
SPLICE PACK
SUNROOF CONTROL MODULE
THEFT DETERRENT ALARM SIREN
TIRE PRESSURE MONITOR MODULE
TRAFFIC INFORMATION RECEIVER (VICS)
TV ANTENNA RADIO MODULE
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> OVERHEAD COURTESY/ FRONT READING LAMPS
