Cadillac STS I (2004-2007) lumbar motor rearward control Wiring diagram
This page shows the only wiring diagram for the component.lumbar motor rearward control, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumbar motor rearward control (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
DOWN
HORIZONTAL
HOT AT ALL TIMES
LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT)
LUMBAR MOTOR DOWN CONTROL
LUMBAR MOTOR FORWARD CONTROL
LUMBAR MOTOR REARWARD CONTROL
LUMBAR MOTOR UP CONTROL
ORG/ WIRE
PASSENGER LUMBAR ADJUSTER SWITCH
PASSENGER LUMBAR MOTOR ASSEMBLY
PNK WIRE
POWER SEAT CIRCUIT BREAKER
RED/WHT WIRE
RWD
VERTICAL
W/ HEATED SEATS
WHT WIRE
Go to component -> Passenger"s lumbar circuit -> LUMBAR MOTOR REARWARD CONTROL
