Cadillac STS I (2004-2007) left rear stop/ turn lamp supply voltage left tail lamp outage detection signal Wiring diagram
This page shows the only wiring diagram for the component.left rear stop/ turn lamp supply voltage left tail lamp outage detection signal, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear stop/ turn lamp supply voltage left tail lamp outage detection signal (1 of 1)
3 6 (W/ HID) (W/O HID)
4 2 (W/ HID) (W/O HID)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DK GRN WIRE
DK GRN/WHT WIRE
FROM UNDERHOOD FUSE BLOCK (LIC/IPM
GRN WIRE
GROUND
GROUND B+
HOT AT ALL TIMES
LEFT FRONT CORNERING/ SIDE MARKER LAMP
LEFT HEADLAMP ASSEMBLY LEFT FRONT PARK LAMP
LEFT PARK LAMP SUPPLY VOLTAGE STOP LAMP SUPPLY VOLTAGE
LEFT REAR CORNERING/ SIDE MARKER LAMP
LEFT REAR STOP/ TURN LAMP SUPPLY VOLTAGE LEFT TAIL LAMP OUTAGE DETECTION SIGNAL
LEFT TAIL LAMP ASSEMBLY
LOGIC
LT BLU WIRE
LT PARK FUSE (DIAGRAM 1 OF 2)
LT PPL
PPL
PPL PPL
RIGHT FRONT CORNERING/ SIDE MARKER LAMP
RIGHT HEADLAMP ASSEMBLY RIGHT FRONT PARK LAMP
RIGHT PARK LAMP SUPPLY VOLTAGE STOP LAMP SUPPLY VOLTAGE
RIGHT REAR CORNERING/ SIDE MARKER LAMP
RIGHT REAR STOP/ TURN LAMP SUPPLY VOLTAGE
RIGHT TAIL LAMP ASSEMBLY
RIGHT TAIL LAMP OUTAGE DETECTION SIGNAL
RT PARK FUSE
SIDE MARKER
SPLICE PACK
STOP LAMP FUSE
STOP LAMP RELAY
STOP TURN
STOP- TURN TAIL
TAIL
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> LEFT REAR STOP/ TURN LAMP SUPPLY VOLTAGE LEFT TAIL LAMP OUTAGE DETECTION SIGNAL
